DATA:
45mm DIN Achromatic Objective:4X,10X,40X(S),100X(S, Oil)
Wide Field Plane-Scope Eyepiece:WF10X,(optional WF16X)；
Total Magnification:40X-1600X;
Articulated Free Binocular Head,Interpupillary Distance:55-75mm；30º Inclined,360º Rotatable;
Built-in Digital Camera System with a USB2.0 cord and Micro-image Process Software ;
Nosepiece:Backward Quadruple Nosepiece;
Double Layers Mechanical Stage:125X125mm, Moving Range X-Y:60X40mm
Ø2-Ø30mm Iris Diaphragm And Ø32 Filter；ABBE Condenser:N.A. 1.25
Coaxial Coarse And Fine Focusing Adjustable Mechanism:14mm
Built-in High Brightness LED Lamp 1W
Net Weight/Set:5kg；
Package:2 Sets/Carton 44X37X47cm；
Gross Weight/Carton:12kg
45mm DIN Achromatic Objective:4X,10X,40X(S),100X(S, Oil)
Wide Field Plane-Scope Eyepiece:WF10X,(optional WF16X)；
Total Magnification:40X-1600X;
Articulated Free Binocular Head,Interpupillary Distance:55-75mm；30º Inclined,360º Rotatable;
Built-in Digital Camera System with a USB2.0 cord and Micro-image Process Software ;
Nosepiece:Backward Quadruple Nosepiece;
Double Layers Mechanical Stage:125X125mm, Moving Range X-Y:60X40mm
Ø2-Ø30mm Iris Diaphragm And Ø32 Filter；ABBE Condenser:N.A. 1.25
Coaxial Coarse And Fine Focusing Adjustable Mechanism:14mm
Built-in High Brightness LED Lamp 1W
Net Weight/Set:5kg；
Package:2 Sets/Carton 44X37X47cm；
Gross Weight/Carton:12kg
