DATA:
45mm DIN Achromatic Objective:4X,10X,40X(S),100X(S, Oil)
Wide Field Plane-Scope Eyepiece:WF10X,WF16X(Optional)；
Total Magnification:40X-1600X
Coaxial Coarse And Fine Focusing Adjustable; Mechanism:14mm,Precision:0.01mm;
Revolving Round Stage:Ø160mm;
360ºRotatable and Graduated 1ºIncrements,Minimum Resolution 6’;
Ø2-Ø30mm Iris Diaphragm And Ø32 Filter; ABBE Condenser:N.A.1.25;
Coaxial Coarse And Fine Focusing Adjustable; Mechanism:14mm,Precision:0.01mm;
Rotatable Analyzer with Graduation 0º-90º,Sliding out of Optical Path;
Optical Compensator:λSlip(first class red),1/4λSlip;
Polarize: On the light collector, 360º Rotatable;
Built-in Adjustable Brightness LED Lamp 1W.
