Observation tube |
Binocular head ,45°inclined and rotating |
|
Trinocular head,45°inclined and rotating, 54~75mm interpupillary distance,±5 degrees diopter control |
|
Binocular head,30°inclined and rotating, 54~75mm interpupillary distance,±5 degrees diopter control |
|
Trinocular head,30°inclined and rotating, 54~75mm interpupillary distance,±5 degrees diopter control |
|
Digital head, 30°inclined and rotating |
|
Eyepiece |
wide field eyepiece WF10X/18,(option pointer and micrometer)
WF15X/13mm,WF20X/10mm |
|
Objective |
Plan achromatic 4X,10X,20X,40XS,100XSO |
|
Infinity plan achromatic 4X,10X,20X,40XS,100XSO |
|
Nosepiece |
Quadruple backward nosepiece |
|
Focusing adjustment |
Low position coaxial coarse and fine focusing adjustment with up limited and tension adjustment. coarse adjustment range: 22mm,fine adjustment precision:0.002mm |
|
Stage |
Coaxial mechanical stage in 140X132mm size and 76x50mm travel range |
|
Condenser |
NA1.2/0.24 wing-out achromatic condenser |
|
Illuminator |
Mail supply 100-240V,6V20W philips halogen lamp with intensity control |
|
Photography adapter |
3.2x photo eyepiece ,photo tube(with PK mount) |
|
Video adapter |
0.35X CTV
0.5X CTV |
|
Other option |
phase contrast objective and condenser
Dark field condenser
Simple polarization |
